Brass is a binary alloy composed of copper and
zinc that has been produced for millennia and is valued for its workability,
hardness, corrosion resistance and attractive appearance.
Properties
Alloy Type: Binary
Content: Copper & Zinc
Density: 8.3-8.7 g/cm3
Melting Point: 1652-1724 °F (900-940 °C)
Moh's Hardness: 3-4
Characteristics
The exact properties of different brasses depend on the composition of the brass alloy,
particularly the copper-zinc ratio.
In general, however, all brasses are valued for their machinability or the ease with
which the metal can be formed into desired shapes and forms while retaining high
strength.
While there are differences between brasses with high and low zinc contents, all brasses
are considered malleable and ductile (low zinc brasses more so). Due to its low melting
point, brass can also be cast relatively easily. However, for casting applications, a
high zinc content is usually preferred.
Brasses with a lower zinc content can be easily cold worked,
welded and brazed. A high copper content also allows the metal to form a protective
oxide layer (patina) on its surface that guards against further corrosion, a valuable
property in applications that expose the metal to moisture and weathering.
The metal has both good heat and electrical conductivity (its electrical conductivity
can be from 23% to 44% that of pure copper), and it is wear and spark resistant.
Like copper, its bacteriostatic properties have resulted in its use in bathroom fixtures
and healthcare facilities.
Brass is considered a low friction and non-magnetic alloy,
while its acoustic properties have resulted in its use in many 'brass band' musical
instruments. Artists and architects value the metal's aesthetic properties, as it can be
produced in a range of colors, from deep red to golden yellow.
Types
'
Brass' is a generic term that refers to a wide range of
copper-zinc alloys.
In fact, there are over 60 different types of brass specified by EN (European Norm)
Standards. These alloys can have a wide range of different compositions depending upon
the properties required for a particular application.
Production
Brass is most often produced from copper scrap and zinc ingots.
Scrap copper is selected based on its impurities, as certain additional elements are
desired in order to produce the exact grade of brass required.
Because zinc begins to boil and vaporizes at 1665°F (907°C), below copper's melting
point 1981° F (1083°C), the copper must first be melted. Once melted, zinc is added at a
ratio appropriate for the grade of brass being produced. While some allowance is still
made for zinc loss to vaporization.
At this point, any other additional metals, such as lead, aluminum, silicon or arsenic,
are added to the mixture to create the desired alloy.
Once the molten alloy is ready, it is poured into molds where it solidifies into large
slabs or billets. Billets - most often of alpha-beta brass - can directly be processed
into wires, pipes, and tubes via hot extrusion, which involves pushing the heated metal
through a die, or hot forging.
If not extruded or forged, the billets are then reheated and fed through steel rollers
(a process known as hot rolling). The result is slabs with a thickness of less than half
an inch (13mm). After cooling, the brass is then fed through a milling machine, or
scalper, that cuts a thin layer from the metal in order to remove surface casting
defects and oxide.
Under a gas atmosphere to prevent oxidization, the alloy is heated and rolled again, a
process is known as annealing before it is rolled again at cooler temperatures (cold
rolling) to sheets of about 0.1" (2.5mm) thick. The cold rolling process deforms the
internal grain structure of the brass, resulting in a much stronger and harder metal.
This step can be repeated until the desired thickness or hardness is achieved.
Finally, the sheets are sawed and sheared to produce the width and length required. All
sheets, cast, forged and extruded brass materials are given a chemical bath, usually
used hydrochloric and sulfuric acid to remove black copper oxide scale and tarnish.
Applications
Brass's valuable properties and relative ease of production
have made it one of the most widely used alloys. Compiling a complete list of all of
brass' applications would be a colossal task, but to get an idea of industries and the
types of products in which brass is found we can categorize and summarize some end-uses
based on the grade of brass used:
Free cutting brass (e.g. C38500 or 60/40 brass):
Nuts, bolts, threaded parts
Terminals
Jets
Taps
Injectors
